IntelliChlor Plus30 Salt Chlorine Generator Cell Only 30k gal

Brand / Model: Pentair IntelliChlor Plus30 Product / Catalog Number: PAC-45-1562 / 523730 Pool Capacity: Up to 30,000 gallons Chlorine Output: Approximately 1.10 lbs of chlorine per 24 hours at full capacity Operating Voltage (Cell Side): 22–39 V DC (requires compatible IntelliChlor Power Center) Amperage: 6.0 amps maximum at rated output Salt Range: Operates between 2,500–4,500 ppm Cell Type: Electrolytic titanium plates with corrosion-resistant coating Self-Cleaning: Reverse polarity function minimizes scale formation Design: Modular — allows replacement of electronics, sensors, or cell components individually Sensor System: High-accuracy conductivity sensor provides precise salt readings Housing Material: UV-resistant, heavy-duty plastic suitable for saltwater environments Dimensions: 18″ × 8″ × 9″ (shipping) Weight: Approximately 8.2 lb Installation: Drop-in compatible with existing IntelliChlor and iChlor systems Display Features: Built-in diagnostics for salt level, output, and cell life status Application: Residential and light commercial pools Maintenance: Periodic inspection and acid washing recommended for extended cell life Certifications: Meets NSF/ANSI safety and performance standards Warranty: Manufacturer warranty provided (varies by distributor)
