Marlin ProMax™ Variable Speed Self-Priming Pool Pump

The Marlin ProMax™ is an American-style, self-priming variable speed pool pump built for energy-efficient residential and light-commercial pool circulation. It uses a V/F mode controller to precisely regulate motor speed anywhere between 450 and 3450 RPM, letting you dial in exactly the flow you need instead of running at full power around the clock. Choose a touch-button or physical button control panel, and switch between an easy automatic mode (factory-preset 3-speed schedule) or a fully custom manual mode. Built-in RS485 communication also allows integration with external automation and keypad controls for whole-system convenience.

  • V/F controlled single-speed motor with adjustable range of 450-3450 RPM for precise flow control
  • Auto mode with factory preset speeds (3000 / 1400 / 2200 RPM) or fully customizable manual mode
  • Touch-button or physical button control panel with rotatable installation orientation
  • RS485 communication interface or external keypad support for remote start/stop control
  • High-efficiency, energy-saving design rated for 5-50°C water and up to 0.3MPa working pressure
Specifications

Specifications

Pronoia Marlin ProMax MPM390VS Variable Speed Self-Priming Pool Pump

The Pronoia Marlin ProMax MPM390VS is a variable speed, self-priming pool pump built around a V/F mode controller for adjustable-speed operation, allowing pump speed to be adjusted based on pool circulation requirements.

Brand Pronoia
Manufacturer Pronoia
Product Name Marlin ProMax
Model/SKU MPM390VS
Series Marlin ProMax
Product Type Variable Speed Pool Pump
Control Panel Type Touch Button Panel
Remote Control Interface External Keypad Control
UPC Not Provided
Speed Control Mode V/F Mode Controller
Adjustable Speed Range 450 – 3450 RPM
Factory Default Speeds Speed 1: 3000 RPM / Speed 2: 1400 RPM / Speed 3: 2200 RPM
Operating Modes Auto (factory default) & Manual
Media (Water) Temperature 5–50°C
Ambient Temperature ≤50°C
Max Working Pressure 0.3 MPa
Voltage/Phase Verify with Manufacturer
Dimensions / Weight Not Provided

Key Features & Performance

V/F Variable Speed Control: The Marlin ProMax MPM390VS uses a V/F mode controller to deliver adjustable-speed operation, allowing flow rates to be matched to pool circulation demand.
Touch Button Panel: The pump is fitted with a streamlined touch button control panel with simple operating logic. The panel housing can be rotated to suit the installation orientation.
Auto & Manual Speed Modes: The pump ships in Auto mode by default with three pre-set speed stages, while Manual mode allows the user to select and modify the speed stage in use.
External Keypad Remote Control: Start and stop operation of the pump can be controlled through the external keypad connection.
High Efficiency Operation: The variable speed design is intended to provide high-efficiency, energy-saving pump operation compared with conventional fixed single-speed pumps.
Installation & Compatibility
  • Panel Orientation: The control panel can be rotated during installation to allow easier viewing and access depending on the plumbing layout.
  • Operating Environment: Confirm ambient temperature stays at or below 50°C and that pumped water temperature remains within the 5–50°C operating range.
  • System Pressure Check: Verify that pool plumbing pressure ratings do not exceed the pump's maximum working pressure of 0.3 MPa.
  • Speed Programming: Review the factory default speed stages before commissioning. Speeds can be reprogrammed within the 450–3450 RPM operating range.
Product Information Disclaimer: Specifications shown for the Pronoia Marlin ProMax MPM390VS are provided for product reference. Values that are not available are marked "Not Provided" or "Verify with Manufacturer" and should be confirmed prior to purchase or installation.

User Safety Disclaimer: This is electrical and pressurized equipment intended for use with pool water circulation systems. Only qualified personnel familiar with electrical and plumbing safety practices should install, wire, or service this pump. Disconnect power before performing maintenance or electrical work.

Installation and Use Disclaimer: The pump must be installed in accordance with applicable electrical, plumbing, and pool equipment installation requirements. Do not exceed the stated operating limits. Auto and Manual speed modes and factory default speed stages should be reviewed and configured by a qualified installer before placing the pump into service.

Liability Disclaimer: MSP Supply / My Swimming Pool Equipment provides this specification information for reference purposes and assumes no liability for damages, injury, or losses resulting from improper installation, modification, or use of this product.

California Proposition 65 Notice: Pool equipment may contain materials, components, or generate byproducts recognized under California law as requiring a Proposition 65 warning. Consult the product packaging or applicable product documentation for specific warning information.
